All the warnings and instructions of this manual should be followed 2.
Remove the plug from the outlet before cleaning. Do not use this unit in very humid and wet places 4. Keep enough space around the unit for ventilation. During flashes of lightning or cracks of thunder, or when the system is not used for a long time, unplug the system power sup Slots and openings of the cabinet should not be blocked. SYSTEM INCLUDES: OWNER’S MANUAL 4 CHANNEL DVR An 80 GB HDD Power Adapter & Cord is installed in the DVR 2 KEYS FOR (DC 12V, 4.5A ) CARTRIDGE 4 CABLES, 4 RCA-RCA HDD SCREWS 8 BNC TO RCA ADAPTERS (for optional HDD) CHECK YOUR PACKAGE TO MAKE SURE THAT YOU RECEIVED THE COMPLETE SYSTEM, INCLUDING THE COMPONENTS SHOWN ABOVE. Connect the AC power cord and plug it into an electrical outlet. The power LED will illuminate GREEN and the HDD LED will also illuminate GREEN. The message seen on the monitor will say “HDD Checking…., Master Hard Drive”, Slave Hard Drive, Not Detected.
It will then go to a Quad Screen and show a camera loss (if there are no cameras connected). The screen will display “LOSS” respectively as shown below. Before operating the DVR press the MENU button and set theĬONTROL - FRONT PANEL: 13 12 11 10 9 12345 678 1. HARD DRIVE UNIT – Removable 80GB HDD installed (Max. SELECT BUTTON – Allows you to select a Sub-Menu option and change a selection 3. MENU - Press the MENU to enter the main menu. Please refer to page 8 for more information on the Menu options 4. STOP – Use this button to stop recording or playback 5. LED INDICATORS – Represents the status of ope PAUSE - During playback, use this button to Pause the video 6. POWER BUTTON – Press the “POWER” button to turn the DVR “ON”, and press and hold for a SHUTTLE RING – REV/ PAUSE/ FF – This shuttle ring has three functions: 1) REV : During playback, turn this button counterclockwise to rewind 10 seconds back 2) PAUSE: Pauses video during playback 3) FF : During playback, turn this button clockwise to Fast Forward the video 4X the speed FF 1: 2 x Forward Speed FF2: 3 x Forward Speed FF 3: 4 x Forward Speed 10. ALARM OUT – This alarm output can be connected to an alarm output relay for trigger devices with a N/O (Normally open) circuit 3.ĪLARM IN SEN1 – SEN4 – These 4 terminals are used to connect external motion sensors, door/window contacts, etc. The video outputs from the desired cameras to these VIDEO INPUT (1-4) - Connect to video a source, such as camera (BNC Connection).
